Excavator Attachments Excavator Root Ripper For Hitachi KOMASTU CAT DOOSAN Sany
YANMAR Rock Ripper For Excavators
Product parameters
| Model | Pin to Pin Distance | Pin Center Diameter | Plate Thickness | Weight | Dimmensions | Suitable Excavator |
| Unit | mm | mm | mm | kg | mm | Ton |
| JWEERI02 | 265 | 15-30 | 50 | 80 | 750*350*400 | 1.5-4 |
| JWEERI04 | 310 | 40-55 | 55 | 160 | 1050*420*500 | 5-9 |
| JWEERI06 | 390 | 60-65 | 65 | 300 | 1250*450*560 | 9-16 |
| JWEERI08 | 465 | 70-80 | 80 | 450 | 1420*510*670 | 16-23 |
| JWEERI10 | 520 | 80-90 | 90 | 770 | 1600*570*810 | 23-30 |
| JWEERI17 | 570 | 90-100 | 90 | 850 | 1650*700*920 | 30-50 |
Product Features
1.Good Abrasion Resistance:Excavator attachments Ripper is made of high strength steel sheet and mounted the superhard protection board.The ripper tooth is made of the special highest strength steel sheet.
2.Good Mechanical Property:Excavator attachments Ripper tooth is made of NM400 special material which surface brinell hardness can reach 400HB and its mechanical property is 3-5 times better than the normal steel sheet's.
3.Longer work time:the high strength board mounted in front of the ripper can protect the ripper body from damage.It can be changed easily.
4.High frequency:help excavator to break and dig at the same time,easy to install and operate
5.OEM service:usually be designed as single tooth,also can be designed as your requirement.
6.Suitable for different work conditions:such as hard earth,weathered granite,frozen ground,stone and rocks to make excavator easily to dig and load
FAQ
Q: Are you a manufacturer / factory?
A: Yes, we are the manufacturer and established in 2006. We can provide much more cost-effective attachments for construction machinery. Our principle is top-class equipment make best products. You can find kinds of top quality
attachments to fit all type of excavators, bulldozers and loaders. We have exported the products to all over the world,
based on our best quality and excellent service. We are sure you will be satisfied with our best after-sale service.
Q: Do you accept OEM?
A: Yes, OEM & customized manufacturing are available. Please send us the drawings, we can produce the products as your request.
Q: Can I have some samples?
A: Of course, sample order is available. Lead time: 2-3 days. Customized samples: About 7-10 days.
